ETL Listed 60W non dimmable led driver with universal 100-277VAC input, 12V&24V constant voltage with high PF>0.99. Indoor & IP67 waterproof types for LED strips, cabinet lighting and fixed signage.
60W Non Dimmable LED Driver | ETL Certified 12V/24V Constant Voltage Power Supply
ETL Listed 60W non dimmable led driver with universal 100-277VAC input, 12V&24V constant voltage with high PF>0.99. Indoor & IP67 waterproof types for LED strips, cabinet lighting and fixed signage.
• Input Voltage: 100-77vac
• Output Voltage: 12VDC
• Output Power: 60w
• Dimming Type: Non dimming
• Warranty: 5 years
• IP Rate: IP67
• Certification: CE ROHS ETL listed
60W Non Dimmable LED Driver | ETL Certified 12V/24V Constant Voltage Power Supply
What Is a 60W Non Dimmable LED Driver
A 60W non dimmable led driver is compact constant voltage power supply specially customized for medium-load fixed-brightness LED lighting projects. Without extra dimming circuit for 0-10V or DALI control, this fixed-output driver keeps steady full voltage output after power-on, delivering uniform brightness for regular low-voltage LED fixtures. Our 60W non dimmable led driver obtains official ETL safety certification tested by Intertek ETL, fully matching US and Canada electrical codes for smooth local project inspection and installation.
Equipped with universal 100-277VAC wide input range, this 60W fixed power unit supports stable 12V and 24V DC constant output, perfectly matching common LED strip lights, kitchen under-cabinet lamps and small-size advertising backlit signs. For residential DIY decoration and small commercial fixed lighting, the 60W non dimmable led driver becomes the most cost-effective power option among all fixed-voltage LED power supplies.
| Model | Input voltage (AC) | Power | Out voltage (DC) | Output current | Product Size(mm) |
|---|---|---|---|---|---|
| PSD-HC60-A12 | 100-277V | 60W | 12V | 5A | 215*48*23 |
| PSD-HC60-A24 | 100-277V | 60W | 24V | 2.5A | 215*48*23 |
| PSD-HC100-A12 | 100-277V | 100W | 12V | 8.3A | 215*48*23 |
| PSD-HC100-A24 | 100-277V | 100W | 24V | 4.15A | 215*48*23 |
| PSD-HC150-A12 | 100-277V | 150W | 12V | 12.5A | 248*48*23 |
| PSD-HC150-A24 | 100-277V | 150W | 24V | 6.25A | 248*48*23 |
| PSD-HC200-A12 | 100-277V | 200W | 12V | 16.6A | 248*87*24.5 |
| PSD-HC200-A24 | 100-277V | 200W | 24V | 8.3A | 248*87*24.5 |
| PSD-HC300-A12 | 100-277V | 300W | 12V | 25A | 288*87*24.5 |
| PSD-HC300-A24 | 100-277V | 300W | 24V | 12.5A | 288*87*24.5 |
| PSD-HC350-A12 | 100-277V | 350W | 12V | 27A | 288*87*24.5 |
| PSD-HC350-A24 | 100-277V | 350W | 24V | 13.5A | 288*87*24.5 |
Core Advantages of Our 60W Non Dimmable LED Driver
Our 60W non dimmable led driver adopts simplified mature circuit design with fewer electronic parts, which effectively reduces internal failure points and long-term heat output. Compared with high-power complex drivers, the 60W compact model runs cooler during continuous daily operation and extends the service lifespan of matched LED lamps, lowering later maintenance expense for installers and end buyers.
We develop two installation versions for this driver series: regular indoor non-waterproof type for dry ceiling and cabinet hidden mounting, plus IP67 waterproof 60W non dimmable led driver for damp courtyard, outdoor garden and rainy open-air installation. Built-in multi-layer safety protection including overload, overvoltage, short-circuit and overheat auto-cutoff, the power supply can avoid damage caused by wrong wiring or accidental load surge.
With slim lightweight casing and pre-reserved mounting holes, users can easily fix this driver inside cabinet gaps or ceiling cavities without occupying extra installation space. High efficiency up to 92% also helps clients cut down daily power consumption for long-running lighting systems.
Typical Applications for 60W Non Dimmable LED Driver
The rated 60W load capacity makes the 60W non dimmable led driver fit most medium-scale fixed lighting occasions. For home usage, it powers room cove ambient strips, TV background decorative lights and kitchen under-cabinet LED lighting. In retail shops and small offices, it serves shelf accent lighting, indoor fixed panel lamps and small backlit brand signage.
The waterproof variant of 60W non dimmable led driver is widely used for yard pathway lights, short landscape strips and small building facade fixed accent lighting. If you need larger wattage fixed power choices, you can check our full collection via Non Dimmable LED Driver series page to compare 100W~300W specifications.
Installation & Selection Tips for 60W Non Dimmable LED Driver
Before picking a 60W non dimmable led driver, calculate total wattage of all connected LED lights first. We recommend leaving 10%~20% spare power margin to prevent long-term overload operation shortening driver service life. Never install indoor-only model in wet outdoor areas; select IP67 waterproof version for exterior damp environments.
When connecting ultra-long LED strip grouping, split loads into multiple groups with separate drivers to prevent terminal voltage drop and uneven lamp brightness. Professional electrician wiring is suggested for commercial construction to comply with local North American electrical regulations.
Why Pick Our ETL Listed 60W Non Dimmable LED Driver
As a specialized LED power manufacturer, every 60W non dimmable led driver goes through strict aging and load inspection before factory shipment to stabilize overall quality. Full ETL certification, stable stock supply and available OEM customized packaging help our products gain trust from North American lighting contractors and wholesale distributors.
